REFOND Textile Testing Machine High Quality Vertical Flammability Chamber

Standards

ASTM D 6413, CALIF TB-117,DOC-FF3/71,16 CFR 16-1615/1616, GB/T 5455.

Product Instruction

Vertical Flammability Tester determines the vertical flame spread for children sleepwear and fabrics.

- Stainless steel test chamber ensures the safety of test.

- Observe the whole testing process through the glass window, records the burning situation.

- The Automatic Flame Controller controls the flame on and off and its height.

- The timer can be used to record the flame time, after flame time and after glow time.

- A variety of testing specimens can be selected according to the testing standard selected..

- The Bunsen burner for vertical burning test and the side burner for children sleepwear test.

Applications

Children's sleepwear or decorative fabric.

List of Consumables

Burner, Specimen Holder.

Product Specifications

- Stainless Steel Chamber

- Glass observation window

- Timer, adjustable timing control in 0.1 second increments

- Automatic flame controller

- Vertical Bunsen Burner and side burner

- Power Supply: AC230V, 50Hz/60Hz

- Dimension: 330(L)×370(W)×840(H)mm

- Weight: approx. 38kg

Order Information

RF2186 Vertical Flammability Tester

RF2186/1 Automatic flame controller

RF2186/2 - Burner × 1pc

- Specimen Holder × 5pcs

- Dead Weights × 1pc

(For ASTM D6413,FTMS 191-5903)

RF2186/3 - Burner × 1 pc

- Specimen Holder × 5pcs

(For DOC-FF3/71, Children Sleepwear)

RF2186/4 - Burner × 1 pc

- Specimen Holder × 5pcs

-Dead Weights × 1pc

(For CALIF TB-117 Resilient Filling Materials Vertical)

RF2186/5 - Ignitor, Clip and Dead weights

(For CPAI-84, tent testing)
